Corning Cat6A UTP LSZH Cable 500mCorning Cat6A UTP LSZH Cable 500m
General Specifications
Product Number UU004891568
Environment Indoor
Category 6A
Cable Type U/UTP
Bandwidth 500 MHz
Halogen-free Yes
Construction Simplex, 4P
Reaction to fire Eca
Environmental Conditions
Temperature Range, Installation 0 °C to 50 °C
Temperature Range, Operation -20 °C to 60 °C
Cable Design
Conductor Copper Wire, AWG 24
Conductor Insulation Halogen-free foam-skin material
Twisting 2 cores to a pair
Outer Jacket Material LSZH™
Outer Jacket Color Green
Mechanical Specifications
Fire Load 1260 MJ/m
Nominal Outer Diameter 7.3 mm x 15 mm
Min. Bend Radius Installation 8x Cable-Ø (over flat side)
Maximum Tensile Strength 160 N
Electrical Characteristics
Conductor resistance unbalance 2 %
Delay skew 45 ns/100 m
Max. loop resistance 190 MΩ*km
Propagation delay 545 ns/100 m
Voltage rating Less than 75 V d.c max and less than 50 V a.c max
Insulation Resistance 5000 MΩ*km
Surface transfer impedance 10 mΩ
Propagation Velocity at >10 MHz (NVP*c) 69 %
Coupling Attenuation 40 dB
Ordering Information
Length 500 m
Weight 97 kg
Weight 97 kg/km
Packing Type Drum
